Katool KT-X95 8,000lb Full Rise Scissor Lift - Pneumatic Lock

KT-X95 Full Rise Scissor Lift by Katool

The KT-X95 is a true powerhouse designed to elevate your lifting game—literally. This advanced hydraulic lift isn’t just for mechanics or gearheads; it’s built for anyone who needs reliable lifting performance. With a robust 8,000-lb capacity and a maximum lift height of 72 inches, the KT-X95 handles a wide variety of tasks with ease, turning your workspace into a hub of efficiency. Its rapid 50-second lift time boosts productivity, while the generously sized 58.9-inch by 24.4-inch platform easily accommodates everything from motorcycles and lawn equipment to bulky furniture or construction materials—whatever the job demands.

The KT-X95’s 2.2kw motor and 20MP rated oil pressure ensure effortless handling of even the most demanding jobs. Meanwhile, self-lubricated parts reduce maintenance, while the flush mount design seamlessly integrates into your workspace. And for continuous operation without overheating, the top-level hydraulic system features a fan-cooled aluminum motor. From automotive enthusiasts looking to stack their car collection to professional mechanics, contractors, and DIYers, the KT-X95 is the ultimate lifting solution.

X95 Specifications:

• Max. lifting capacity: 8000lbs
• Lifting height: 72.3 inch
• Lifting time: 50S
• Platform length: 58.9 inch
• Platform width: 24.4 inch
• Motor power: 2.2kw
• Rated oil pressure: 20MP
• Air pressure: 6-8kgf/c
• Oil: AW-46 or AW-32 (colder climates)
• Optional: Support Bars
  • Overall Length: 73"
  • Pin Distance: 48" to 59" Wide
  • Adapter Height: 6.2" to 8" Tall

Katool X95 Special Features:

• 8000lbs lifting capacity
• Lock Style: Pneumatic
• CE Approved and Certified. It has adopted the 115% dynamic loading capacity standard and was 150% static loading capacity tested
• Flush mount design
• Starting-up system design
• 24V safe control system
• Height limit switch
• Composite rubber lifting blocks included
• Comes with self-lubricated bushing and bearing
• Drive-up ramps lock design as platform extension for long vehicles
• Top-level hydraulic system and aluminum motor with the fan on top to avoid overheating caused by long time working
• The unit needs to be connected to a compressed air source.

• Includes: Caster Kit for Mobility
• Power: 220V/60Hz, single phase
• Katool Warranty:
  • One-year (12 months) warranty on all parts and against all product defects, free of charge to our customers, on all equipment.
  • Vehicle lifts will include an additional three-year (36 months) warranty on all lift structural components only.
• Optional: Support Bars - Sold Separately
  • Support Bars spread the weight out evenly and have more adjustment for lifting SUVs and full frame vehicles.
