BendPak PL-6000DC 6,000 Lb. Capacity 2 Post Parking Lift

BendPak PL-6000DC 6,000 Lb. Capacity 2 Post Parking Lift

The BendPak PL-6000DC 2 post parking lift is designed to offer efficient vehicle storage and parking solutions without sacrificing usability or safety. With a rated lifting capacity of 6,000 lb, it is capable of handling sedans, SUVs, and many light trucks. Its design is optimized for both long-term and short-term parking applications, such as residential garages, commercial facilities, or office buildings seeking to maximize parking density.

This 2 post parking lift features dual telescoping direct-drive hydraulic cylinders. This means the lift does not rely on chains or screw mechanisms, which simplifies maintenance and improves reliability. As the platform lowers, gravity helps drive it down, which means that no motor power is consumed during descent—this lowers operating cost and reduces wear. The posts can be ganged together with shared columns, allowing multiple lifts to be installed side by side while minimizing wasted space. This shared-column design offers flexibility in layout planning, especially where multiple vehicle parking is needed in tight footprints.

For electrical requirements, the PL-6000DC 2 post parking lift supports 220–420 V, single or three phase. The hydraulic power pack is rated around 2.2 kW. Normal lift and lower times are approximately 50 seconds for lifting, and 45 seconds for lowering, under typical load conditions.

Contact us for more information on BendPak 2 post parking lifts.

Low Operating Cost

Platform driven by gravity when lowered. No electric motor consumption is required.

Fast and Easy Installation

Installation is fast and easy. Detailed installation manual is provided along with floorplan and foundation drawings and video attached with products will help customers have easier installation work.

Ganged/Shared Columns

The posts can be shared which allows multiple installations in minimum space and reduces cost.

Professional Packing & Delivery

Professional packaging and our experienced logistic team ensures customers will get the product damage free. Compact package size means simple unloading and handling.

Dependable Hydraulic Operation

The PL-6000DC features dual telescoping direct-drive cylinders eliminating the need for lifting chains or screw mechanisms and offer better reliability, smoother operation and less maintenance costs.

Automatic Safety Device

Powerful load-holding devices automatically engage and lock the lift structure as the parking lift raises, preventing sudden free fall in the unlikely event of a suspension component failure. Typically, after the lift is raised to the required working height, operators are instructed to lower the lift until it is resting safely on the locks to minimize wear on suspension components.

Safety Features

• Mechanical safety locks are spaced every 4 inches
• 24v operator controls and lock release
• Electric protection for power overload or improper voltage
• Automatic locking system during power outage
• Emergency stop button
• Upper limit switch
• Pressure relief valve and pressure compensated flow control valve to ensure safe operation and level lifting
• Industrial-grade hydraulic cylinders feature a single-piece, pilot fitted, machined steel piston, wrapped with specially designed, pressure loaded U-cup piston seals, backups and wear bands to virtually eliminate fluid bypass
